理论与研究 边慧光 等·齿轮式滤胶机过滤全钢胎气密层实验研究

定的提升。实现了在同配方的情况下的性能提升，在 Bhowmick.Functionalized graphene with polymer as unique
strategy in tailoring the properties of bromobutyl rubber
一定情况下可以降低成本。
nanocomposites." Polymer 82 (2016):121-132.
（2）在不同目数的滤网下过滤气密层时，胶料 [6] Vickers, Neil J.Animal communication: when i’m calling
的气密性和力学性能的提升也不相同，在 150 目时， you, will you answer too?.Current biology 27.14 (2017):
R713-R715.
胶料的性能提升的幅度最大，其中透气系数降低了
[7] Torrent, Miquel, Pedro Javier Gamez-Montero, and Esteban
78%，撕裂强度提升了 20%。 Codina.Parameterization, modeling, and validation in real
conditions of an external gear pump.Sustainability 13.6
参考文献 ： (2021):3 089.
[1] Yilkiran, Ing Timur. Tires and system solutions for the cars [8] 邬志敏 , 螺杆式制冷压缩机新技术应用的进展 . 制冷 2.6
of the future." 8th International Munich Chassis Symposium (2002).
2017: chassis. tech plus. Springer, 2017. [9] 王闯 . 水润滑双螺杆空压机工作过程传热传质特性研究 ." 机
[2] 杨建，王国林，万治君 . 子午线轮胎的非自然平衡轮廓设计及 械工程学报 57.8 (2021):247-254.
性能分析 . 中国机械工程 26.13 (2015):1 827. [10] Mckane, Aimee T.Improving compressed air system
[3] Neves, Renato Ramirez Viana, Giancarlo Barbosa Micheli, performance: A sourcebook for industry.(2003).
and Marcílio Alves . An experimental and numerical [11] Mikulionok, I. O.Classification of Extruder Filters
investigation on tyre impact.International Journal of Impact for Processing Polymeric Materials and Rubber
Engineering 37.6 (2010):685-693. Mixtures (Survey of Designs).Chemical and Petroleum
[4] Cai, Fei, et al.The relationship between specific structure Engineering 58.3 (2022): 248-255.
and gas permeability of bromobutyl rubber: a combination [12] 李泽汉 . 基于齿轮泵的短纤维增强橡胶复合材料挤出成型机理
of experiments and molecular simulations.Macromolecular 及实验研究 [D]. 青岛科技大学，2018.
Theory and Simulations 28.6 (2019):1 900 025. [13] 朱晓瑶 . 槟榔纤维素短纤维增强天然胶乳复合材料制备机理与
[5] Kotal, Moumita, Shib Shankar Banerjee, and Anil K. 实验研究 [D]. 青岛科技大学，2019.

Experimental study on the gas tight layer of all steel tire filtered
by a gear type rubber filter

1
1
1
1
2
Bian Huiguang , Gu Xihong , Wang Chuansheng , Sui Zhihua , Zhu Donglin , Hao Guoqiang 1
(1.Qingdao University of Science & Technology, Qingdao 266042, Shandong, China;
2.Jiangsu Wuxi Double Elephant Rubber & Plastics Machinery Co. LTD., Wuxi 214000, Jiangsu, China)
Abstract: The butyl mixed rubber after processing in the ordinary way can not meet the airtightness
requirements of high-load tires.So the gear pump head is added to the original rubber filter to achieve both
high-pressure extrusion and fine filtration of rubber. In the same material of the tire rubber formula, the use
of self-developed dual-drive synchronous rubber gear pump rubber filtering machine for the airtight layer
of fine rubber filtration in order to study the performance of the rubber after filtration. By replacing different
screens, the degree of improvement in the performance of the rubber is investigated by the mesh size of the
screen. The performance of the rubber material filtered by the gear pump rubber filter machine has different
degrees of enhancement. In the 150 mesh, the performance has the largest increase，inculding 20.21%
increased of tear strength.It indicating that the filter mesh filtering rubber impurities at the same time can
also smooth the molecular chain.The higher the mesh, more smoother the molecular chain，meanwhile, the
higher the resistance to the rubber material during filtration.The resistance disappears after filtered, due to
the thermal movement and micro-configuration transformation, the molecular chain will be spontaneously
restored to the chaotic state, resulting in the mechanical properties of the rubber material will first rise and
then fall .The permeability coefficient is reduced by 78.11%, the symmetrical distribution of methyl groups in
nitrile, the molecular structure is symmetrical, which makes the aggregated state structure stacking closely.
